Bilstein 24-185387 is a nitrogen-gas-charged monotube shock absorber for the vehicle applications shown below. It measures 17.94 in extended and 13.19 in compressed, with stud upper and eyelet lower mounts. Supplied as a single shock, it should be matched to the required suspension position and fitment details.
Specifications
| Brand | Bilstein |
| Manufacturer Part Number | 24-185387 |
| Type | Nitrogen Gas Charged |
| With Coil Spring | No |
| Internal Design | Monotube |
| Adjustable | No |
| Upper Mounting Style | Stud |
| Lower Mounting Style | Eyelet |
| Body Color | Yellow |
| Quantity | Single |
| Valving Type | Deflective Disc Valving |
| Rod Finish | Polished |
| Rod Material | Steel |
| Body Material | Steel |
| With Reservoir | No |
| Includes Dust Shield | No |
| Includes Hardware | Yes |
| Includes Boot | Yes |
| Estimated Install Time (Hours) | 0.5 |
Dimensions
| Extended Length (IN) | 17.94 in |
| Compressed Length (IN) | 13.19 in |
| Rod Diameter (IN) | 0.55 in |
Key Features
- Monotube design, nitrogen gas-charged.
- Direct fit upgrade to factory equipment.
- Easily adapts to any road surface.
- Extends the service life of any SUV, van, or truck.
- Least expensive nitrogen gas upgrade.
- Easy, direct bolt-on installation.
- Limited lifetime warranty.
- Bilstein shocks are revered the world over for their quality, performance, and value – and the Bilstein 4600 series is considered by many to be the company’s most consumer-friendly product.
- Bilstein 4600 monotube shock absorbers are the least expensive and most effective upgrade to extend the service life of any vehicle out on the road today.
Compatibility
Vehicle Applications
- 2000 Toyota Tundra
- 2001 Toyota Tundra
- 2002 Toyota Tundra
- 2003 Toyota Tundra
- 2004 Toyota Tundra
- 2005 Toyota Tundra
- 2006 Toyota Tundra
- 2001 Toyota Sequoia
- 2002 Toyota Sequoia
- 2003 Toyota Sequoia
- 2004 Toyota Sequoia
- 2005 Toyota Sequoia
- 2006 Toyota Sequoia
- 2007 Toyota Sequoia
