Bilstein 24-196437 is a nitrogen-gas-charged monotube shock absorber for the vehicle applications shown below. It measures 18.27 in extended and 13.8 in compressed, with cross pin upper and clevis lower mounts. Supplied as a single shock, it should be matched to the required suspension position and fitment details.
Specifications
| Brand | Bilstein |
| Manufacturer Part Number | 24-196437 |
| Type | Nitrogen Gas Charged |
| With Coil Spring | No |
| Internal Design | Monotube |
| Adjustable | No |
| Upper Mounting Style | Cross Pin |
| Lower Mounting Style | Clevis |
| Body Color | Yellow |
| Quantity | Single |
| Valving Type | Deflective Disc Valving |
| Rod Finish | Polished |
| Rod Material | Steel |
| Body Material | Steel |
| With Reservoir | No |
| Includes Dust Shield | No |
| Includes Hardware | Yes |
| Includes Boot | Yes |
| Estimated Install Time (Hours) | 0.5 |
Dimensions
| Extended Length (IN) | 18.27 in |
| Compressed Length (IN) | 13.8 in |
| Rod Diameter (IN) | 0.55 in |
Key Features
- Monotube design, nitrogen gas-charged.
- Direct fit upgrade to factory equipment.
- Easily adapts to any road surface.
- Extends the service life of any SUV, van, or truck.
- Least expensive nitrogen gas upgrade.
- Easy, direct bolt-on installation.
- Limited lifetime warranty.
- Bilstein shocks are revered the world over for their quality, performance, and value – and the Bilstein 4600 series is considered by many to be the company’s most consumer-friendly product.
- Bilstein 4600 monotube shock absorbers are the least expensive and most effective upgrade to extend the service life of any vehicle out on the road today.
Compatibility
Vehicle Applications
- 2011 Chevrolet Silverado 2500 HD
- 2011 Chevrolet Silverado 3500 HD
- 2011 GMC Sierra 2500 HD
- 2011 GMC Sierra 3500 HD
- 2012 Chevrolet Silverado 2500 HD
- 2012 Chevrolet Silverado 3500 HD
- 2012 GMC Sierra 2500 HD
- 2012 GMC Sierra 3500 HD
- 2013 Chevrolet Silverado 2500 HD
- 2013 Chevrolet Silverado 3500 HD
- 2013 GMC Sierra 2500 HD
- 2013 GMC Sierra 3500 HD
- 2014 Chevrolet Silverado 2500 HD
- 2014 Chevrolet Silverado 3500 HD
- 2014 GMC Sierra 2500 HD
- 2014 GMC Sierra 3500 HD
- 2015 Chevrolet Silverado 2500 HD
- 2015 Chevrolet Silverado 3500 HD
- 2015 GMC Sierra 2500 HD
- 2015 GMC Sierra 3500 HD
- 2016 GMC Sierra 2500 HD
- 2016 Chevrolet Silverado 3500 HD
- 2016 GMC Sierra 3500 HD
- 2016 Chevrolet Silverado 2500 HD
- 2017 Chevrolet Silverado 2500 HD
- 2017 Chevrolet Silverado 3500 HD
- 2017 GMC Sierra 2500 HD
- 2017 GMC Sierra 3500 HD
- 2018 Chevrolet Silverado 2500 HD
- 2018 Chevrolet Silverado 3500 HD
- 2018 GMC Sierra 2500 HD
- 2018 GMC Sierra 3500 HD
- 2019 Chevrolet Silverado 2500 HD
- 2019 Chevrolet Silverado 3500 HD
- 2019 GMC Sierra 2500 HD
- 2019 GMC Sierra 3500 HD
- 2020 Chevrolet Silverado 2500 HD
- 2020 Chevrolet Silverado 3500 HD
- 2020 GMC Sierra 2500 HD
- 2020 GMC Sierra 3500 HD
- 2021 Chevrolet Silverado 2500 HD
- 2021 Chevrolet Silverado 3500 HD
- 2021 GMC Sierra 2500 HD
- 2021 GMC Sierra 3500 HD
- 2022 Chevrolet Silverado 2500 HD
- 2022 Chevrolet Silverado 3500 HD
- 2022 GMC Sierra 2500 HD
- 2022 GMC Sierra 3500 HD
- 2023 Chevrolet Silverado 2500 HD
- 2023 Chevrolet Silverado 3500 HD
- 2023 GMC Sierra 2500 HD
- 2023 GMC Sierra 3500 HD
- 2024 Chevrolet Silverado 2500 HD
- 2024 Chevrolet Silverado 3500 HD
- 2024 GMC Sierra 2500 HD
- 2024 GMC Sierra 3500 HD
- 2025 Chevrolet Silverado 2500 HD
- 2025 Chevrolet Silverado 3500 HD
- 2025 GMC Sierra 2500 HD
- 2025 GMC Sierra 3500 HD
- 2026 Chevrolet Silverado 2500 HD
- 2026 Chevrolet Silverado 3500 HD
- 2026 GMC Sierra 2500 HD
- 2026 GMC Sierra 3500 HD
